HCVAC ऑटोमोटिव कार लाइट क्रोम प्लेटिंग कोटिंग मशीन उपकरण

We produce both vertical and horizontal for our full automatic car light vacuum coating equipment.Main function of this machine including high voltage ion bombard, coat aluminum film and hard SiOx protective film at one time inside the vacuum chamber. Hard SiO protective film improves the capability of anti- nitriding and keeps the high reflective rate of aluminum film for long time.

The reflective coating film reaches the national standard for the car light. It passed the acid, alkali, salt test. Machine adopts the computor control and monitor of the running state and coating process. It can improve the working efficiency and ensure the stability and consistency of the product quality, reduce the effect of human factors.

 Headlamp vacuum coating machine working Principle:

The whole process like vacuum pumping, plasma cleaning, Al film and the SiOx protective film coating, deflating etc. is all running fully automatically.

Two doors (optional) with 6-axis (also 8 axis optional) rotation &revolution jig and evaporation motor. When handle the workpiece in one door. It can upload and unload the workpiece and install AL materials in another door at the same time. So the production performance is very excellent.

The aluminum deposition adopts resistance heating evaporation source, complex three-dimensional structure can also be uniform deposited.

SiOx protective film coating system is optional.

Specifications:





Mode Dimension	ZZ-1214	ZZ-1416	ZZ-1618	ZZ-1820
	1200*1400mm	1400*1600mm	1600*1800mm	1800*2000mm
Film Type	Semitransparent film, non-conducting film, gold, silver, red, blue, green, purple, seven color, etc.
Power source Type	Thermal evaporation power, ion bombard power, RF power
Vacuum chamber structure	Vertical double/single door, horizontal single door, pump system postposition
Ultimate vacuum	8.0*10-4Pa
Vacuum system	Diffusion pump +Roots pump +Mechanical pump +Holding pump
Pump time	Pump from atmosphere to 5.0*10-2,6 minutes
Workpiece motion mode	Public rotation/Frequency control
Control mode	Manual/Automatic all-in-one mode, Touching screen+PLC
Remark	We can design the dimension of the vacuum chamber according to customers demand.
